Graphite coated hard facing electrode performs exceptionally well under extreme abrasive and sliding wear at operating temperatures upto 800°C. Applications include screw conveyers impact breaker strips, slag crushers, sand blasting plants, mixers, kneaders, baffle plates, etc.

An advanced electrode for welding of carbon steel and austenitic manganese steels for applications encountering abrasion and erosion at elevated temperatures. The deposit consists of high percentage of special constituents which retain abrasion resistance upto 650°C.

Remove all damaged and fatigued weld metal and clean weld area. Maintaining short to medium arc length, deposit stringer or 1 ½ X weaved beads. For high carbon steels, preheat upto 250°C. Use “Excel Bond 086” as a cushion alloy if more build up is required. For austenitic manganese steels, do not allow temperature of parts to rise more than 150°C and use “Excel Bond 004” as cushion layer. Slow cool after welding.

1. Current: AC/DC +                2. Hardness: 55 – 60 HRC
