EXCEL BOND 001

EXCEL BOND 001

TYPICAL APPLICATION

Containers, ducts, tank, transport bodies, pipe lines, Guards.

PRODUCT FEATURES

  1. Contact type electrode suitable for all position welding.
  2. Uniform Ripple quality.
  3. Excellent weldability.
  4. Minimum distortion due to minimum heat input to base metal

RECOMMENDATIONS

Excellent product for welding all position welding on thin steel sheets to avoid distortion & warpage. Most suitable for all steel fabrication of low carbon steel with the rapid deposition rate.

PROCEDURE

Clean area to be welded. Suitable for using on AC or DC power source. Remove slag between multiple passes. Do not remove slag in hot condition as on cooling, it will be released by itself. Do not weave while welding in thin sheet to avoid warpage.

RECOMMENDED AMPERAGES

SIZE (mm)AMPERAGE
5.00165 – 190
4.00140 – 165
3.15105 – 130
2.580 - 90

TECHNICAL DATA

1. Tensile Strength: 70,000 psi
